Dynatron G199 1U CPU Cooler with Fan for LGA 1366 Socket - Perfect for Server Rack & Data Center Cooling

Product Description

Dynatron G199 socket 1366 1U Cooler

CPU Socket :1366
CPU Support:
Intel® Xeon™ 5600 series Westmere Processor X5680, X5677, X5670, X5667, X5660, X5650, E5645, E5640, E5630, E5620, L5640, L5638, L5630, L5618, L5609 & 5500 Series Nehalem EP Processor W5580, X5570, X5560, X5550, E5540, E5530, E5520, E5506, E5504, E5502, L5520, L5506, L5518, L5508
Solution :1U
Overall Dimension : 90.0 x 90.0 x 27.7 mm
Weight : 475 g
Material : Copper Heatsink
Fan Dimension: 70 x 70 x 15 mm
Speed
At Duty Cycle 0%: 1100 RPM
At Duty Cycle 20%: 1100 RPM
At Duty Cycle 100%: 6000 RPM
Bearing: 2 Ball Bearing
Rated Voltage: 12 V
Power:
At Duty Cycle 0%: 0.6 W
At Duty Cycle 20%: 0.6W
At Duty Cycle 100%: 8.76 W
Air Flow:
At Duty Cycle 0%: 2.45 CFM
At Duty Cycle 20%: 2.45 CFM
At Duty Cycle 100%: 14.32 CFM
Noise Level :
At Duty Cycle 0%: 19.1 dBA
At Duty Cycle 20%: 19.1 dBA
At Duty Cycle 100%: 53.8 dBA
Lead Wire Pin Out :
Pin1-Black (-)
Pin2-Yellow (+)
Pin3-Green (Tachometer/Signal output)
Pin4-Blue (PWM)

Note:
1. Backplate is not included
2. RoHS Compliance
