Dynatron R5 CPU Cooler - High Performance Cooling for Gaming PCs & Workstations | Perfect for Overclocking & Silent Operation

Intel

LGA 2011 (Square Type, 80mm x 80mm Mounting Pitch) / LGA 2066

2U Server and Up

91.5 x 91.5 x 66.0 mm

590 g

At Duty Cycle 0~20%: 1700 ± 200 RPM
At Duty Cycle 50%: 4000 ± 10% RPM
At Duty Cycle 100%: 8000~8500 RPM

H.C.C. (Heatpipes Contact CPU) Copper Base & Aluminum Fins with Heatpipes Embedded

12V

60 x 60 x 25 mm

2 Ball Bearing

Duty Cycle 0~20%: 1.2 W
At Duty Cycle 50%: 2.5 W
At Duty Cycle 100%: 9.6 W

At Duty Cycle 0~20%: 9.86 CFM
At Duty Cycle 50%: 23.21 CFM
At Duty Cycle 100%: 49.32 CFM

At Duty Cycle 0~20%: 19.32 dBA
At Duty Cycle 50%: 37.89 dBA
At Duty Cycle 100%: 54.26 dBA

At Duty Cycle 0~20%: 0.86 mm-H2O
At Duty Cycle 50%: 4.76 mm-H2O
At Duty Cycle 100%: 21.50 mm-H2O

Pin1- (-)
Pin2- (+)
Pin3- (Techometer/Signal output)
Pin4- (PWM)
