Dynatron Q10 Intel LGA 1700 2U Server CPU Cooler - High Performance Cooling Solution for Data Centers & Workstations

Product Description

Dynatron Q10 Intel 1700 2U CPU Cooler

840556075455

Dynatron Q10 Intel 1700 2U CPU Cooler is also a suitable option for the Intel® Core™ i9 processor. It is compatible with socket FCLGA 1700, has an aluminum radial fin heat sink with a copper core, and is an active cooler designed for 2U servers and larger. The Q10 also supports up to 125 watts of CPU power heat dissipation.

PRODUCT SPECIFICATIONS:

• CPU Support: Intel®
• CPU Socket: LGA 1700
• Solution: 2U Server & Up
• Dimensions: 106 x 106 x 62 mm
• Lead Wire Pin Out: Pin#1-Black(-)

  Pin#2- Yellow(+)
  Pin#3- Green(Tachometer/ Signal Output)
  Pin#4- Blue (PWM)

• Thermal Grease: Shin-Etsu 7762 Pre-Printed
• Fan Dimension: 77 CM Plastic Fan with 4-Pin PWM Connector, 5500RPM
• Bearing Type: Double Ball
• Rated Voltage: 12 VDC
• Speed:  At Duty Cycle 20%: 1000 RPM

  At Duty Cycle 50%: 2600 RPM
  At Duty Cycle 100%: 5500 RPM


• Power: At Duty Cycle 20%: 0.54 W

  At Duty Cycle 50%: 1.68 W
  At Duty Cycle 100%: 9.0 W

• Air Flow: At Duty Cycle 0~20%: 8.36 CFM

  At Duty Cycle 50%: 25.53 CFM
  At Duty Cycle 100%: 53.9 CFM


• Noise Level: At Duty Cycle 20%: 20.6 dBA

  At Duty Cycle 50%: 35.1 dBA
  At Duty Cycle 100%: 51.4 dBA


• Air Pressure: At Duty Cycle 20%: 0.240 mm-H2O

  At Duty Cycle 50%: 1.250 mm-H2O
  At Duty Cycle 100%: 5.590 mm-H2O

• Material: Aluminum Radial fin Heat Sink with Copper Core Inserted
• Weight: 430g

Dynatron Q10 Intel 1700 2U CPU Cooler
